Jet JWL-1221VS 12 In x 21 In Variable Speed Wood Lathe - 719200

Jet JWL-1221VS 12 In x 21 In Variable Speed Wood Lathe - 719200

The JET 1221VS is different from anything we’ve made before. In truth, it’s different from anything that anybody has ever made before. The design is better. The features are better. The entire turning experience is better. And it all focuses on one concept… Control.


Features

• Unrivaled speed control
• 60-3600 RPM variable speed
• Optimally designed speed ranges
• Forward to reverse is a smooth transition
• Innovative ratchet style belt tension system (patent pending)
• Integrated, spring loaded spindle lock
• Conveniently located controls and DRO
• Acme thread in tailstock
• 24 integrated indexing positions

Specifications

• Swing Over Bed (In.): 12-1/2
• Swing Over Tool Rest Base (In.): 9-9/20
• Distance Between Centers (In.): 20-1/2
• Spindle Bore (In.): 3/8
• Spindle Taper: MT2
• Spindle Thread (In./TPI): 1"/8 TPI
• Number of Indexing Positions: 24
• Motor Power (HP): 1
• Motor Voltage (V.): 115
• Prewired Voltage (V.): 115
• Recommended Circuit Size (Amps.): 10
• Assembled Machine Dimensions (In.): 33-3/5L x 11W x 17-7/10H



---
