- Four Workstations: Standard (3) - Punch, Flat Bar Shear & Angle Shear; Open (1) - Customize your ironworker with 12 optional Attachments
- 12 interchangeable Attachments available to tailor the Ironworker to your needs
- 17 optional Accessories available to increase precision and efficiency
- Compact machine that allows for fast and easy transitions between fabrication operations: punch, shear, notch, bend or cope all in one machine
- ANSI B11.5- 1988(02) Compliant Guarding
- ETL/UL Approved Controls
- Integrated E-Stop, Lock-out/Tag-out
- Optimized workstation heights for improved efficiency
- Electric foot pedals with integrated jog control
- Adjustable electric stoke control
- Flat Bar Shear Max Round Capacity (In.)7/8 diam.
- Flat Bar Shear Max Capacity (In.)3/8 x 14, 1/2 x 12, 3/4 x 4
- Angle Shear Max Capacity (In.)3 x 3 x 3/8, 4 x 4 x 1/4
- Angle Shear Work Height (In.)39-7/8
- Open Workstation Throat Depth (In.)11-3/16
- Open Workstation Work Height (In.)34-1/2
- Motor5 HP 230V 3Ph
- Amps14
- Hydraulics (PSI)2500
- Hydraulics (GPM)3-1/2
- Product Dimensions (In.)44-3/8 x 36-1/8 x 55-1/4
- Hydraulic Reservoir (Gal.)7
- Shipping Dimensions (In.)45 x 51 x 62
- Height62.0000
- Length45.0000
- Weight2480.0000
- Width51.0000
