Dake 75 ton Hand Operated Presses - 907003
The 75H hand operated hydraulic press offers 75 tons of pressing power. This press is 87 inches tall and offers 29 5/8 inches of workhead travel, 44 inches between the uprights, and 36 inch ram to table maximum.
Features:
- Hand operation for economical performance.
- By-pass hole prevents excessive ram extension.
- Rapid screw traverse of ram permits quick, easy movement of the ram by means of a convenient handwheel.
- Rapid ram return starts as soon as release valve is opened and may be stopped at any point by closing the valve
- Adjustable table permits easy vertical movement by means of self-locking hoist.
Standard Equipment:
- Frame
- 2 Steel V-Blocks
- Flat Ram Nose
- Pressure Gauge
- Workhead
- 2 Steel Table Plates
- Self-Locking Table Hoist
Frame
- 2 Steel V-Blocks
- Flat Ram Nose
- Pressure Gauge
- Workhead
- 2 Steel Table Plates
- Self-Locking Table Hoist
Specs:
- Number: 907003
- Capacity: 75 tons
- Operation: Hand
- Horsepower: n/a
- Voltage: n/a
- Width between uprights: 44"
- Width between table channels: 8-1/4"
- Minimum ram to table: 6"
- Maximum ram to table: 36"
- Ram travel: 4-1/2"
- Screw Travel: 7"
- Horizontal work-head travel: 29-5/8"
- Footprint: 55" x 36"
- Height: 87"
- Weight: 1,245 lbs
- Base: 55" x 36"
- Ram advance speed: n/a
- Pressing speed: n/a
- RPM: n/a
- Air Pressure: n/a
