Dake Ratchet Lever Arbor Press 5 Ton - Model 4M
Floor model 5 ton arbor press with hand-operated brake.
Features:
- Ratchet device permits lever to be used in most convenient position.
- Counterweight returns lever quickly after downstroke.
- Handwheel advanced ram to work quickly.
Standard Equipment:
- Cast Iron Base
- Handwheel
- Ram
- Notched Table Plate
- Counter weight
Specs:
- Number: 902006
- Capacity: 5 tons
- Leverage ratio: 55:1
- Ram size: 2" x 2" x 23"
- Maximum diameter work: 20”
- Throat: 10”
- Largest arbor: 5 1/4”
- Maximum ram to table: n/a
- Minimum ram to table: n/a
- Capacity over table: 26”
- Capacity over table plate: 24 1/2”
- Base length: 21 1/2”
- Base width: 29”
- Weight: 1045 lbs
* specifications subject to change without notice.
