Jet 6 In x 48 In Industrial Belt Finishing Machine 1Ph - J-4300A - 414600
This JET Combination Belt and Disc Machine offers every user a desirable combination of power, precision and versatility. Belt changes are quick and easy, and mitering applications are no problem for a superior finish to every job
Features:
- For added safety, the J-4300A follows strict guidelines and electrical requirements to be certified by CSA Group
- Table tilts 45° out and 20° in for all angle finishing operations
- Completely enclosed drums and guarded sanding belt
- Variable position locks, the belt head adjusts vertically and horizontally
- Adjustable dust deflector and dust chute
- Fine thread adjustments for simple and easy belt tracking
- Adjustable, heavy-duty, cast iron removable platen
- Removable upper belt guard for contour finishing
- Heavy-duty one-piece steel stand
- Miter gauge included
Specifications:
- Belt Size (W x L) 6 x 48
- Belt Speed (SFPM) 2,850
- Table Slots (In.) 5/8
- Belt Table Tilt (Deg.) 45 Out, 20 In
- Belt Table Size (In.) 7-3/8 x 14-3/4
- Motor (HP) 1-1/2 HP, 115/230V, 1Ph
- Overall Dimensions 29 x 16 x 58
- Weight (Lbs.) 215
