Description
•1.57" maximum drilling capacity
•Heavy duty construction
•Power down feed
•MT4 spindle
•39.3" Reach
•9.4" Column
•Box Shape Worktable
Specifications
- Item Number: RD-1000M
- Max. Drill Capacity: 1.57"
- Distance from Spindle to Column Center: 7.8" to 39.3"
- Diameter of Column: 9.4"
- Spindle Taper: MT4
- Spindle Travel: 9.8"
- Spindle Speed Range: 71 to 1800 rpm
- Range of Spindle Feeds: .005" to .02"
- Spindle Feeds: 4
- Distance Between Spindle Nose and Base: 10.3" to 41.8"
- Table Size: 15.7" x 17.7" x 15.7"
- Base Size: 29" x 20"
- Overall Size: 68" x 29.5" x 93"
- Motor: 4 hp
- Power: 220V 3-phase
- Shipping Weight: 3,740 lbs.
- Shipping Dimensions: 74" x 39" x 87"
- * specifications subject to change without notice.
